N2000H V3 Appliance
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7.14.2 Removing a PCIe Card from the Mainboard
This topic describes how to remove a Peripheral Component Interconnect Express (PCIe) card
from the mainboard before replacing the PCIe card with a new one.
Scenarios
Remove a PCIe card before replacing it with a new one.
Prerequisites
Conditions
You have powered off the N2000H V3. For details, see 3.2 Powering Off.
You have removed the chassis cover from the N2000H V3. For details, see 5.6
Removing the Chassis Cover.
Data
You have determined the position on the N2000H V3 for removing a PCIe card.
You have obtained the rack number and chassis number of the N2000H V3.
You have located the N2000H V3 based on the preceding information, and labeled its
panel to prevent misoperations.
Tools
ESD gloves
Packaging materials, for example, an ESD bag
Procedure
Step 1 Open the PCIe card latch. See step (1) in Figure 5-28.
Step 2 Lift the PCIe card slowly out of the slot. See step (2) in Figure 5-28.
