N2000H V3 Appliance
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 7-28 Removing a PCIe card from the mainboard
Step 3 Place the removed PCIe card in an ESD bag.
----End
7.15 Installing a PCIe Card
This topic describes how to install a Peripheral Component Interconnect Express (PCIe) card
on the riser card and on the mainboard.
7.15.1 Installing a PCIe Card on the Riser Card
This topic describes how to install a Peripheral Component Interconnect Express (PCIe) card
on the riser card.
Scenarios
Install a PCIe card.
Prerequisites
Conditions
You have powered off the N2000H V3. For details, see 3.2 Powering Off.
