N2000H V3 Appliance
User Guide
7 Replacing Parts
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
228
7.41 Installing a Rear Hard Disk Backplane
This topic describes how to install a rear hard disk backplane to replace the original one.
Scenarios
The original rear hard disk backplane has failed.
Prerequisites
Conditions
You have powered off the N2000H V3. For details, see 3.2 Powering Off.
You have removed the chassis cover from the N2000H V3. For details, see 5.6
Removing the Chassis Cover.
Data
You have determined the position on the N2000H V3 for installing the rear hard disk
backplane.
You have obtained the rack number and chassis number of the N2000H V3.
You have located the N2000H V3 based on the preceding information, and labeled its
panel to prevent misoperations.
Tools
ESD wrist strap or ESD gloves
M3 Phillips screwdriver
Packaging materials, for example, an ESD bag
Procedure
Install a rear hard disk backplane for 12 disks.
a. Take the spare rear hard disk backplane out of the ESD bag.
b. Hook the rear hard disk backplane, and move it downward until its latch
automatically locks. see Figure 5-83.
