N2000H V3 Appliance
User Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Table 1-9 describes the N2000H V3 technical specifications.
Table 1-9 Technical specifications
Dual-CPU configuration: one or two Intel® Xeon® E5-2600 v3 series
CPUs:
Maximum thermal design power (TDP): 135 W
Number of cores per CPU: 16 (2.3 GHz), 14 (2.6 GHz), 12 (2.6
GHz), 10 (2.6 GHz), 8 (3.2 GHz), 6 (3.4 GHz) and 4 (3.5 GHz)
Number of QPI links: 2
Maximum transmission speed per QPI link: 9.6 GT/s
Maximum L3 cache capacity: 35 MB
Single-CPU configuration: one Intel® Xeon® E5-2600 v3 series CPU:
Maximum TDP: 120 W
Number of cores per CPU: 16 (2.3 GHz), 14 (2.6 GHz), 12 (2.6
GHz), 10 (2.6 GHz), 8 (3.2 GHz), 6 (3.4 GHz) and 4 (3.5 GHz)
Number of QPI links: 2
Maximum transmission speed per QPI link: 9.6 GT/s
Maximum L3 cache capacity: 35 MB
Dual-CPU configuration: up to 16 DDR4 DIMM slots (8 DIMMs per
CPU) for installing either RDIMMs or LRDIMMs; single-CPU
configuration: up to eight DDR4 DIMM slots for installing either
RDIMMs or LRDIMMs:
16 x 16 GB RDIMMs for two CPUs, with a maximum memory
capacity of 256 GB
Maximum memory speed: 2133 MHz
Memory protection technologies: Error Checking and Correction
(ECC), memory mirroring, Single Device Data Correction (SDDC),
memory sparing, and lockstep
The N2000H V3 supports the following hard disk configurations:
− N2000H V3 with 36 + 4 hard disks:
24 front 3.5-inch SAS HDDs, SATA HDDs, or SSDs + 12 rear
3.5-inch SAS HDDs, SATA HDDs, or SSDs + 4 built-in 3.5-inch
SAS HDDs, SATA HDDs, or SSDs
Hard disks are hot-swappable.
The Appliance supports RAID 0, 1, 10, 1E, 5, 50, 6, and 60. It
protects cache data from power failures, and supports RAID state
migration, RAID configuration memory, self-diagnosis, and
web-based configuration.
The mainboard can be configured with a SAS adapter or SAS RAID
controller card (with a maximum of 2 GB cache) to improve hard
disk storage performance and ensure user data security.
