N2000H V3 Appliance
User Guide
4 Configuring the N2000H V3
Issue 04 (2018-11-06)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
71
Figure 4-4 Querying the health status for the N2000H V3
d. Clear alarms by referring to the HUAWEI Rack Appliance Alarm Handling (iBMC).
If the query result in c indicates that no alarm is generated for the Appliance, skip this step.

Check the N2000H V3 using the iBMC CLI.
a. Log in to the iBMC over the CLI.
i. Set an IP address for the PC, and ensure that the IP address is on the same
network segment as the iBMC management network port.
ii. Connect the PC to the N2000H V3 iBMC management network port by using
a network cable.
iii. Run the Secure Shell (SSH) tool on the PC, and enter the IP address of the
iBMC management network port, user name, and password to log in.
To log in to iBMC over SSH is secure by default. If the SSH service is disabled, enable the SSH service
on the Config > Port Settings page on the WebUI of iBMC.
b. View the N2000H V3 version information.
Check that the N2000H V3 versions meet the site requirements.
iBMC / # ipmcget -d ver
------------------- iBMC INFO -------------------
IPMC CPU: Hi1710
IPMI Version: 2.0
CPLD Version: (U46)1.05
Active iBMC Version: (U25)1.62
Active iBMC Built: 22:00:15 Jun 12 2015
Backup iBMC Version: 1.59
SDK Version: 1.51
SDK Built: 17:00:37 May 17 2015
Active Uboot Version: 1.1.35 (Mar 25 2015 - 10:24:41)
Backup Uboot Version: 1.1.35 (Mar 25 2015 - 10:24:41)
----------------- Product INFO -----------------
Product ID: 0x0001
Product Name: N2000H V3
BIOS Version: (U47)1.36
-------------- Mother Board INFO ---------------
Mainboard BoardID: 0x0002
