6.5.7 Replacing an Air Exhaust Temperature Sensor
Prerequisites
The air exhaust temperature sensor needs to be replaced.
A spare and functional temperature sensor is available.
Context
Recommended tools: diagonal pliers and cable ties
Preparation: maintain from the front door.
Procedure
Step 1 Remove the front door and signal cables of the controller.
Step 2 Remove components of the fans (the second to the sixth from up to bottom).
Step 3 Remove the cable ties fastening the air exhaust temperature sensor.
Step 4 Remove the waterproof plug of the air exhaust temperature sensor probe and replace the
probe, as shown in Figure 6-7.
Step 5 Use the cable tie to fix the new air exhaust temperature sensor to the original position.
Step 6 Install the fan components.
Step 7 Connect the signal cables to the controller and install the front door.
Figure 6-7 Replacing the air exhaust temperature sensor
----End
