Figure 5-7 Common Functions
5.8.1 Status
On the Status screen, you can query operating status of the air conditioning system, including
CW (chilled water) valve, indoor fan, cond (condensate) pump, remote on/off, and EMS
(element management system).
Tap Common Functions > Status on the home screen to enter the Status screen, as shown in
Figure 5-8.
The system on or EMS on function is available only when the remote dry contact is on the status of
system on (The remote dry contact does not connect to anything).
Figure 5-8 Status
5.8.2 Operating Info
The Operating Info screen displays the current detected temperature, humidity, voltage, dew
point temp, and anti-cond protection.
