6.5.8 Replacing an Air Intake Temperature Sensor
Prerequisites
The air intake temperature sensor needs to be replaced.
A spare and functional temperature sensor is available.
Context
Preparation: maintain from the rear door.
Procedure
Step 1 Remove the rear door and air filters.
Step 2 Use a Phillips screwdriver to loosen the R-shaped cable pipe clamp fastening the temperature
sensor on the rear door post and remove the air intake temperature sensor, as shown in Figure
6-8.
Step 3 Remove the waterproof plug of the temperature sensor probe and replace the probe.
Step 4 Secure the new air intake temperature sensor to the original position using the cable pipe
clamp and fix the temperature sensor probe using the R-shaped cable pipe clamp.
Step 5 Install the air filters and the rear door.
Figure 6-8 Air intake temperature sensor
----End
