Huawei NetCol5000-C - Securing the Netcol5000-C Onto a Support

NetCol5000-C Chilled Water-Cooled In-Row Precision
Air Conditioner
User Manual
3 Installation Guide
Issue 02 (2013-12-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
31
Step 3 Place a slide plate beside the securing plate.
Step 4 Push the NetCol5000-C to the installation position along the slide plate as shown in Figure
3-13.

Take care to prevent the NetCol5000–C from falling over.

Two people are required to hold the NetCol5000–C on both sides and gently push it
towards the installation position.
Figure 3-13 Pushing the NetCol5000-C
----End
3.10 Securing the NetCol5000-C onto a Support
Prerequisites

The support meet the requirement has been required.

NetCol5000-C has been transported to the destination.
Procedure
Step 1 Secure the support onto the ground, for details see Bases for the IDS2000 User Manual 01.
Step 2 Place the NetCol5000-C on the support.
