NetCol5000-C Chilled Water-Cooled In-Row Precision
Air Conditioner
User Manual
2 Product Description
Issue 02 (2013-12-10)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
11
Item
Description
Fan speed characteristic
Stepless speed adjustment
Total airflow
5100 m
3
/h
Maximum operating
pressure
1.6 MPa
Air filter
G3 filter
Condensate pump
Yes
Dimensions
(W x D x H)
300 mm × 1000 mm × 2000 mm
300 mm × 1200 mm × 2000 mm
Packing dimensions
(W x D x H)
760 mm × 1350 mm × 2200 mm
Net weight/Gross
weight
240 kg/250 kg
Pipe and cable routing
Installed on a concrete floor or an ESD floor
Environmental
certification
RoHS, WEEE and REACH
1: The return air dry-bulb temperature / wet-bulb temperature is 37.8 °C/ 20.8 °C, the temperature of
chilled water is 10 °C and flow is 5.04 m
3
/h.
2.8 Performance Curves
Cooling Capacity and Water Supply
With rated power and maximum air volume, the NetCol5000-C has different performance
specifications for cooling capacity, sensitive heat, and water supply based on chilled water
temperatures and temperature rises. Table 2-4, Table 2-5, Table 2-6, Table 2-7, and Table 2-8
list the performance specifications.
Table 2-4 Specifications for a 5.5°C chilled water supply system
Item
Performance Specifications
Return air
temperature
Dry-bulb
temperature (°C)
40
37
35
32
28
Wet-bulb
temperature (°C)
21.4
20.5
19.8
18.9
17.6
5°C
temperature
Cooling capacity
(kW)
40.63
36.79
33.21
29.27
23.98
