6.5.10 Replacing a Monitoring Module
Prerequisites

The monitoring module needs to be replaced.

A spare and functional monitoring module is available.
Context
Preparation: maintain from the rear door.
Procedure
Step 1 Remove the rear door and air filters.
Step 2 Remove cables from the monitoring module front panel.
Step 3 Remove the monitoring module from the power distribution subrack, as shown in Figure 6-10.
Step 4 Replace the monitoring module, insert the new monitoring module to the corresponding slot
of the power distribution subrack, and connect cables to the monitoring module.
Step 5 Install the air filters and rear door.
Figure 6-10 Replacing the monitoring module
----End
6.5.11 Replacing a Rectifier
Prerequisites

The rectifier needs to be replaced.
