Figure 3-6 Support specifications
You can prepare support by yourself.
3.5 Removing the Cabinet Doors
Prerequisites
NetCol5000-C has been transported to the destination.
Do not move the front door too far away from the cabinet. Otherwise, the cables connecting
the control panel and then NetCol5000–C will be damaged.
Procedure
Step 1 Unlock the doors.
Step 2 Pull the doors outwards by using both hands.
Step 3 Remove the cable from the control panel.
Step 4 Push the doors upwards by using both hands until they are removed, as shown in Figure 3-7.
