Figure 3-7 Removing the cabinet doors
----End
3.6 Removing the Filters
Procedure
Step 1 Rotate the six baffle plates at the top, middle, and bottom to remove them from the filters, as
shown in Figure 3-8.
Step 2 Pull the rope to the filters outwards.
The side with a metal mesh is the internal side.
Step 3 Take out the desiccant bag from behind the column in the lower right corner beside the rear
door.
