Step 7 Connect the signal cables to the controller panel, install the upper part of the front door and
lock the door.
Pay attention to the fasteners when pushing the controller panel from the right or left side to
prevent the controller panel from being damaged.
Figure 6-15 Replacing the controller panel
----End
