Figure 3-2 Gradient of the NetCol5000-C
Choose mechanical transportation tools such as the pallet truck to unload and transport the
NetCol5000-C. Insert the tines of the pallet truck in the middle. Move the NetCol5000-C with
caution to prevent the NetCol5000-C from tilting.
Be careful for the equipment as it is easy to fall over.
Figure 3-3 Moving the NetCol5000-C by using a pallet truck
