NetCol5000-C Chilled Water-Cooled In-Row Precision
Air Conditioner
User Manual
3 Installation Guide
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
42
Figure 3-24 Connecting power cables (routing from the top)
Figure 3-25 Connecting power cables (routing from the bottom)
Connect the standby power cable to the X200 port by referring to Figure 3-24 and Figure 3-25.
