HUAWEI NetEngine40E Universal ServiceRouter

Hardware Description

4 NE40E-X3 Chassis Overview

Issue 01 (2012-09-30)

Huawei Proprietary and Confidential

Figure 4-4 Components of the NE40E-X3 AC chassis

1. MPU

2. LPU

3. Cabling rack

4. AC Power module

5. Rack-mounting ear

6. Air intake vent

7. Handle

8. Air filter

9. Ground terminal

10. Fan

4.1.4 Slot Layout on the NE40E-X3

Figure 4-5 shows the slot layout on the NE40E-X3.

Figure 4-5 Slot layout on the NE40E-X3

MPU 4

LPU 1

LPU 3

LPU 2

MPU 5
