Table B-3 lists the typical configuration of the NE40E-X3.
Table B-3 Typical configuration of the NE40E-X3
Platform
Description
40G
1*Chassis+2*MPU+3*LPUF40+6*2-Port10GE FPIC
B.2 Boards
Table B-4 lists the Basic Configuration of the NE40E. Table B-5 shows the LPUs and the
corresponding Flexible Plug-in Cards (FPICs) supported by the NE40E.
Table B-4 Basic Configuration of the NE40E
Product
Name
BOM
Numbe
r
Board
Name
for
Order
Full Name
NE40E-X
16
0235193
1
CR5B0B
KP1670
NE40E-X16 Integrated Chassis Components
03030JT
W
CR5D0M
PUB460
Main Processing Unit
0305354
7
CR5DSF
UIE07B
Switch Fabric Unit
03030K
SX
CR5DSF
UI407B
Switch Fabric Unit
NE40E-X
8
0235193
0
CR5B0B
KP0870
NE40E-X8 Integrated Chassis Components
0305420
7
CR5D0S
RUA770
Switch and Route Processing Unit A7
0305354
9
CR5D0S
RUA570
Switch and Route Processing Unit A5
03030K
SR
CR5D0S
RUA470
Switch and Route Processing Unit A4
03030K
SY
CR5DSF
UI407C
40Gbps Switch Fabric Unit C
0305423
0
CR5DSF
UIA07D
100Gbps Switch Fabric Unit D(SFUI-100-D)
0305354
8
CR5DSF
UIE07C
200Gbps Switch Fabric Unit C(SFUI-200-C)
NE40E-X
3
0235159
6
CR5Z1B
KPE
NE40E-X3 Integrated DC Chassis Components
