A List of Indicators
This chapter presents the list of indicators.
A.1 Indicators of NE40E-X16
This chapter presents the indicators of NE40E-X16.
A.2 Indicators of NE40E-X8
This chapter presents the indicators of NE40E-X8.
A.3 Indicators of NE40E-X3
This chapter presents the indicators of NE40E-X3.
A.4 Indicators of NE40E-8
This chapter presents the indicators of NE40E-8.
A.1 Indicators of NE40E-X16
This chapter presents the indicators of NE40E-X16.
A.1.1 Fan Module Indicators
Table A-1 shows the status and descriptions of the indicators.
Table A-1 Description of the indicators on the fan module
Indicator
Color
Description
STATUS
Green
If the indicator blinks once
every two seconds (0.5 Hz),
it indicates that the fan
module works normally.
Red
If the indicator is steady on,
it indicates that the fan
module,PEM or filtering
box is faulty.
