Table 6-73 Attributes of 100GBase-CFP optical modules
Attributes
Description
Transmission distance
10 km ( 6.21 mi. )
10 km ( 6.21 mi. )
Center wavelength
1310 nm
1550 nm
Minimum transmitting
power
-4.3 dBm
-2.8 dBm
Maximum transmitting
power
4.5 dBm
3.5 dBm
Receiving sensitivity
-8.6 dBm
-8.8 dBm
Overload power
4.5 dBm
3.5 dBm
Optical fiber type
Single-mode
Single-mode
Technical Specifications
Table 6-74 lists technical specifications of the 1-Port 100GBase-CFP Integrated Line Process
Unit.
Table 6-74 Technical specifications of the 1-Port 100GBase-CFP Integrated Line Process Unit
Item
Specifications
Silk screen of the board name
LPUI-100
1x100GE-CFP
Power consumption
About 339 W
Heat dissipation
1100 BTU/hour
Dimensions (width x depth x height)
400 mm x 520 mm x 40 mm ( 15.75 in. x 20.47
in. x 1.57 in. )
Weight
About 9.2 kg ( 20.29 lb )
6.8 Line Processing Unit S (LPUS-100)
This chapter describes the structure and specifications of the Line Processing Unit S
(LPUS-100).
