5 NE40E-8 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
124
Item
Technical Parameter
Maximum output current
-48V/62.5A
Maximum output power
3000 W
Capacity for user's air circuit breaker in
power distribution
25 A ( Vin = 180 V AC ) ; 16 A( Vin = 220
V AC )
5.3 Heat Dissipation System
This section describes the components of the heat dissipation system of the NE40E-8.
The weight of the fan frame of NE40E-8 is 5 kg ( 11.03 lb ), and the depth is 520 mm ( 20.47
in. ). Be careful when removing a fan module to prevent causing injuries to the human body
or damages to the fan module.
The heat dissipation system of the NE40E-8 consists of the following components:

Fan modules

Air intake frame

Fans built in the power supply module

Air filters
Figure 5-9 shows the air flow inside the NE40E-8.
