Parameter
Unit
Value
(RMS) spectral width
Maximum spectral width
(-20 dB)
nm
0.88
Minimum side mode
suppression ratio (SMSR)
dB
30
Average transmit optical power
Maximum transmit optical
power
dBm
-3
Minimum transmit optical
power
dBm
-9
Minimum extinction ratio
dB
6
Optical receiver
Operating wavelength range
nm
1260-1360
Receiver sensitivity
dBm
-19.5
Overload power
dBm
-3
Maximum optical channel
cost
dB
N/A
Maximum reflection factor
dB
N/A
D.13 40Gbps TRANSPONDER Optical Modules
Table D-53 lists the available 40Gbps TRANSPONDER optical modules.
Table D-53 40Gbps TRANSPONDER optical modules
Model
BOM
Number
Interface
Standard
Transmis
sion
Distance
(km)(mi)
Mode
Wavelen
gth (nm)
Remarks
Transpond
er-300PIN
-39.8~41.
3Gbps-2.5
~2.7Gbps-
1550nm-0
~3dBm--7
dBm-LC-
2km
34120002
OC-768,S
TM-256,G
.709,OUT
-3
2(1.24)
NRZ
1550
-
