HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7.9.3 Technical Specifications
75-ohm Relay Cable
Table 7-35 shows the technical specifications of the 75-ohm trunk cable.
Table 7-35 Technical specifications of the 75-ohm trunk cable
Coaxial connector-SMB plug-75 Ω/straight/female
Coaxial cable-SYV-75-2-2(4.0Z)-1/0.34 mm-outer diameter 3.9
mm-double braid shielded
5 m ( 16.40 ft ), 10 m ( 32.81 ft ), 20 m ( 65.62 ft ), 30 m ( 98.42
ft ), 40 m ( 131.23 ft ), 50 m ( 164.04 ft ), 65 m ( 213.25 ft ), 70 m
( 229.66 ft ), 90m ( 295.27 ft ), and 100 m ( 328.08 ft )
120-ohm Relay Cable
Table 7-36 shows the technical specifications of the 120-ohm trunk cable.
Table 7-36 Technical specifications of the 120-ohm trunk cable
Network interface connector-8 PIN-8 bit-shielded-crystal
model plug
Symmetric pair cable-120 ohm-SEYPVPV-0.4 mm-26
AWG-8 PIN-PANTONE 430 U-Special OEM
2 m ( 6.56 ft ), 15 m ( 49.21 ft ), 30 m ( 98.42 ft ), 60 m
( 196.85 ft ) and 80 m ( 262.46 ft )
7.10 24xE1 Cable
This section describes the structure and technical specifications of the 24xE1 cable.
7.10.1 Overview
The E1 interface on the NE40E uses 100-ohm trunk cables. One end of the 24xE1 cable is
connected to the E1 electrical interface on the device using the D-100 connector; the other end
of the 24xE1 cable is connected to the Digital Distribution Frame (DDF) using a connector
that needs to be made as required on site.
