Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
2 NE40E-X16 Chassis Overview
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
7
Table 2-1 Board distribution in the board cage of the NE40E-X16
Slot
Number
Quant
ity
Slot Width
Remarks
1 to 16
16
41 mm (1.6 inches)
These slots are used to hold LPUs.
17 to 18
2
41 mm (1.6 inches)
These slots hold MPUs that work in 1:1
backup mode.
19 to 22
4
41 mm (1.6 inches)
These slots are used to hold SFUs that
work in 3+1 load balancing mode.
2.1.6 System Configuration
This section describes the system configuration and physical parameters of the NE40E-X16.
Table 2-2 System configuration list of the NE40E-X16
Item
Description
Remarks
Processing unit
Main frequency: 1.5 GHz
-
BootROM
8 MB
-
SDRAM
2 GB
Can be extended to 4 GB.
NVRAM
4 MB
-
Flash
32 MB
-
CF card
4 GB
Two 2 GB CF cards.
Switching capacity
12.58 Tbit/s
(bidirectional)
-
Interface capacity
3.2 Tbit/s (bidirectional)
-
Number of LPU slots
16
-
Number of MPU slots
2
-
Number of SFU slots
4
-
2.2 Power Supply System
This chapter describes the power supply system used by the NE40E.
2.2.1 Architecture of the Power Supply System
This section describes the features of the power supply system.
The NE40E-X16 supports either DC or AC power supply.
