Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
D Optical Module
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
724
Parameter
Unit
Value
Optical receiver
Operating wavelength range
nm
1260-1360
Receiver sensitivity
dBm
-19.5
Overload power
dBm
-8
Maximum optical channel
cost
dB
N/A
Maximum reflection factor
dB
N/A
D.12 1.25 Gbit/s CSFP Optical Module
The 1.25 Gbit/s CSFP optical modules can be used on 1 GE interfaces. The transmitting
center wavelength of a 1.25 Gbit/s CSFP optical module is 1490 nm, the receiving center
wavelength is 1310 nm, and the transmission distance is 10 km (6.21 mi.).
The 1.25 Gbit/s CSFP optical modules can be used only on 48-port 100/1000Base-CSFP flexible cards.
Table D-50 lists the currently available 1.25 Gbit/s CSFP optical modules.
Table D-50 1.25 Gbit/s CSFP optical modules
Product
Model
BOM
Number
Interface
Standard
Transmis
sion
Distance
(km)
Mode
Wavelen
gth (nm)
Remarks
OD-BD12
23-35SL
34060525
1000BAS
E-BX
10 (6.21
mi.)
Single-mo
de
1490TX/1
310RX
It is
connected
to a single
fiber that
has a
transmittin
g end and
a
receiving
end. It
does not
support
self-loop.
PTC3830-
554CW-L
C/PC+
34060525
1000BAS
E-BX
10 (6.21
mi.)
Single-mo
de
1490TX/1
310RX
It is
connected
to a single
fiber that
has a
transmittin
g end and
a
