7.10.2 Structure
The 24xE1 cable uses the D-100 connector on one end, as shown in Figure 7-15.
Figure 7-15 Appearance of the 24×E1 cable
Figure 7-16 shows the structure of the 24xE1 cable.
Figure 7-16 Structure of the 24×E1 cable
100-ohm 24xE1 cable wiring
Table 7-37 describes the wiring of the 100-ohm 24xE1 cable.
Table 7-37 100-ohm 24×E1 cable wiring
