Item
Specifications
IEEE802.3ad Link aggregation
IEEE 802.1p Label
IEEE 1588v2 (PTP)
Interface type
SFP
RJ-45
Reliability and
availability
Hardware feature

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C ( 32°F to 113°F )
Short-term ambient temperature: -5°C to +55°C ( 23°F to 131°F )
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 0% to 95%
Storage conditions
Storage temperature: -40°C to +70°C ( -40°F to 158°F )
Storage humidity: 0% to 95%
6.15.8 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A
Overview
Either the LAN or WAN mode can be configured for each interface on the 2-Port 10GBase
WAN/LAN-SFP+ Flexible Card A. The flexible card occupies a flexible card slot, and can be
installed on the LPUF-50. the 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A can only
used on slot 0 and slot 1.
Figure 6-114 shows the appearance of the 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A.
Figure 6-114 Appearance of the 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A
Panel
Table 6-294 lists the indicators on the panel.
