4.5 Physical Specifications
This chapter describes the specifications of the chassis and boards.
4.5.1 Chassis Specifications
Table 4-15 lists the physical parameters of the NE40E-X3.
Table 4-15 Physical parameters of the NE40E-X3
Item
Description
Dimensions (width x depth x
height)
DC chassis: 442 mm x 650 mm x 175 mm ( 17.40 in.
x 25.59 in. x 6.89 in. )(chassis main body
dimensions)442 mm x 750 mm x 175 mm (17.40 in.
x 29.53 in. x 6.89 in. )(chassis dimensions including
the chassis's front and rear assembly and cable racks)
AC chassis: 442 mm x 650 mm x 220 mm ( 17.40 in.
x 25.59 in. x 8.66 in. )(chassis main body
dimensions)442 mm x 750 mm x 220 mm (17.40 in.
x 29.53 in. x 8.66 in. )(chassis dimensions including
the chassis's front and rear assembly and cable racks)
Installation position
N68E cabinet or a standard 19-inch cabinet
Typical power consumption
1100 W
Maximum power consumption = Typical power
consumption * 1.1
Heat dissipation
3569 BTU/hour
Weight
Empty chassis
DC chassis: 12 kg ( 26.46 lb )
AC chassis: 20 kg ( 44.1 lb )
Full
configuration(m
aximal)
DC chassis:

36kg ( 79.38 lb )(with LPUF-21)

41kg ( 90.41 lb )(with LPUF-40)
AC chassis:

46kg ( 101.43 lb )(with LPUF-21)

51kg ( 112.46 lb )(with LPUF-40)
DC input
voltage
Rated voltage
-48 V
Maximum
voltage range
-38 V to -72 V
AC input
voltage
Maximum
voltage range
90 V to 275 V AC
175 V to 275 V AC(recommend)
System
MTBF (year)
37.35
