HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Table 7-15 Cable type of the AC-input power cable
External Suite,Power Cords All Over The World,Class I Equipment
With Connector C19,External Cable Set
7.2.4 NE40E-8 AC-input Power Cable
Table 7-16 lists the types and terminals of the AC-input power cable.
Table 7-16 Cable types and cable terminals of the AC-input power cable
Power cable -6mm^2-black jacket (core line: brown) -36A
Power cable -6mm^2-black jacket (core line: blue) -36A
Power cable -6mm^2-black jacket (core line: yellow or green) -36A
Bare terminal -OT-6mm^2-M4-tin plating-round pre-insulated
terminal-12-10AWG-yellow
Bare terminal -OT-6mm^2-M8-tin plating-round pre-insulated
terminal-12-10AWG-yellow
7.3 Chassis and Cabinet Grounding Cable
This section describes the structure and technical specifications of the chassis and cabinet
ground cable.
7.3.1 Introduction
The chassis and cabinet ground cables are used to ground a chassis and a cabinet. Before the
delivery of a device, ground cables are correctly connected to the front, back and side doors of
the cabinet.
7.3.2 Structure
The connector of the chassi and cabinet ground cable is the same as the connector of the
DC-input power cable.
7.3.3 Technical Specifications
Table 7-17 lists the technical specifications of the chassis and cabinet ground cable..
