Item
Description
Storage altitude
Lower than 5000 m ( 16404 ft )
As shown in the table, "width" does not involve the dimensions of rack-mounting ears.
As shown in the table, "width" does not involve the dimensions of rack-mounting ears. The
measurement point of the temperature and humidity is 1.5 m ( 4.92 ft ) over the floor and 0.4 m ( 1.31 ft )
in front of the cabinet without the front and back doors.
Short-term operation means that continuous operating time does not exceed 48 hours and accumulated
operating time per year does not exceed 15 days. If an operation exceeds either of these conditions, it is
called a long-term operation.
Table 3-36 lists the typical configuration of the NE40E-X8.
Table 3-36 Typical configuration of the NE40E-X8
Platform
Description
40G
2*Fan+4*DC Power+2*SRU+1*SFU+8*LPUF40+16*2-Port10GE
FPIC
100G
2*Fan+4*DC
Power+2*SRU200A+1*SFU200C+8*LPUF100+16*5-Port10GE
FPIC
3.6.2 Board Specifications
Table 3-37 lists the specifications of boards supported by the NE40E-X8.
Table 3-37 Specifications of boards supported by the NE40E-X8
Type
Description
Silkscreen
SRU
SRUA5
SRUA
SRUA4
SRUA
SRUA7
SRUA
SFU
SFU
SFUI-200-C
SFU
SFUI-40-C
SFU
SFUI-100-D
SPU
SPU
SPU
Flexible Card Versatile
Service Unit 10
VSUF-10
Integrated Versatile Service
Unit 20 A
VSUI-20-A
