HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
If the indicator is on, the system is in the alarm state. If
the indicator is off, the system is in the normal state.
If the indicator is on, the SRU is in the active state. If the
indicator is off, the SRU is in the standby state.
If the indicator is blinking, data is being read or written.
If the indicator is off, no data is being read or written.
NOTE
When the indicator is blinking, do not remove the CF card.
LINK indicator
(on the Ethernet
interface)
If the indicator is off, the link is Down. If the indicator is
on, the link is Up.
LINK indicator
(on the Ethernet
interface)
If the indicator is off, no data is being read or written. If
the indicator is blinking, data is being read or written.
A.4.4 SFU Indicators
Table A-20 lists the status and descriptions of SFU indicators.
Table A-20 SFU indicators
If the indicator is on, you can remove a board.
If the indicator blinks once every 2s (0.5 Hz), the SFU is
in the normal state. If the indicator blinks twice every 1s
(2 Hz), the SFU is in the alarm state.
If the indicator is on, the SFU is in the normal state. If the
indicator is off, the SFU is in the abnormal state.
A.4.5 LPU Indicators
Table A-21 lists the status and descriptions of LPU indicators.
Table A-21 LPU indicators
If the indicator is on, you can remove the board.
If the indicator blinks once every 2s (0.5 Hz), the
FPIC is in the normal state state.
If the indicator blinks twice every 1s (2 Hz), the FPIC
is in the alarm state.
