Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
413
Item
Specifications
availability

Supporting hot swap
NMS
Enhanced command-line interface
SNMP and MIB support
Operating
conditions
Long-term ambient temperature: 0°C to 45°C
Short-term ambient temperature: -5°C to +55°C
Long-term relative humidity: 5% to 85%
Short-term relative humidity: 0% to 95%
Storage conditions
Storage temperature: -40°C to +70°C
Storage humidity: 0% to 95%
6.16.10 20-Port 10/100/1000Base-RJ45 Flexible Card
Overview
Figure 6-139 shows the appearance of the 12-port 10/100/1000Base-RJ45 FPIC.
Figure 6-139 Appearance of the 20-Port 10/100/1000Base-RJ45 FPIC
Panel
Figure 6-140 shows the panel appearance of the 20-Port 10/100/1000Base-RJ45 FPIC. Table
6-376 describes the indicators on the panel.
Figure 6-140 Panel appearance of the 20-Port 10/100/1000Base-RJ45 FPIC
