Huawei NetEngine40E Hardware Description

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
6 Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
414
Table 6-376 Indicators on the panel of the 20-Port 10/100/1000Base-RJ45 FPIC
Indicator
Description
STATUS
indicator (green)
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state. If the indicator blinks twice every 1s (2 Hz), the
FPIC is in the alarm state.
Interface Attributes
Table 6-377 lists the interface attributes of the 20-Port 10/100/1000Base-RJ45 FPIC.
Table 6-377 Interface attributes of the 20-Port 10/100/1000Base-RJ45 FPIC
Attributes
Description
Connector type
RJ45
Working mode
10M/100M/1000M auto-sensing and half-duplex and full-duplex
Cable specification
Category 5 unshielded twisted pair (UTP) cable recommended when
the interface works at 10 Mbit/s or 100 Mbit/s; super category 5
Shielded Twisted Pair (STP) cable recommended when the interface
works at 1000 Mbit/s..
Frame format
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
Network protocol
IP
Technical Specifications
Table 6-378 lists the technical specifications of the 20-Port 10/100/1000Base-RJ45 FPIC.
Table 6-378 Technical specifications of the 20-Port 10/100/1000Base-RJ45 FPIC
Item
Specifications
Silk screen of the board
name
P40-20 x FE/GE-RJ45
Power consumption
(typical value)
About 27 W
Heat dissipation
88 BTU/hour
Board weight
About 0.50 kg ( 1.10 lb )
Dimensions (width x
depth x height)
178 mm x 125 mm x 35 mm ( 7.01 in. x 4.92 in. x 1.38 in. )
Connector type
RJ45
Earliest software
version
V600R003C00
