HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 6-115 Appearance of the 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A
Table 6-293 Indicators on the panel of the 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A
If the indicator blinks once every 2s (0.5 Hz), the FPIC is in the
normal state state.
If the indicator blinks twice every 1s (2 Hz), the FPIC is in the alarm
state.
LINK/ACT
indicator(green)
If the indicator is on, the link is Up.
If the indicator is blinking, the data is being read or written.
If the indicator is off, the link is Down.
Interface Attributes
Table 6-294 lists the interface attributes of the 2-Port 10GBase WAN/LAN-SFP+ Flexible
Card A.
Table 6-294 Interface attributes of the 2-Port 10GBase WAN/LAN-SFP+ Flexible Card A
Optical
interface
attributes
Compliant with the selected SFP+ optical module.
Ethernet_II, Ethernet_SAP, and Ethernet_SNAP
