HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Figure 7-12 Structure of 120-ohm trunk cable
The pin assignments of the 120-ohm trunk cable are shown in Table 7-34.
Table 7-34 Pin assignments of the 120-ohm trunk cable
The structure of the 75-ohm (with SMB connectors on both ends) trunk cable is shown in
Figure 7-13.
Figure 7-13 Structure of the 75-ohm (with SMB connectors on both ends) trunk cable
The structure of the 75-ohm (with SMB connector on either end) trunk cable is shown in
Figure 7-14.
Figure 7-14 Structure of the 75-ohm (with SMB connectors on either end) trunk cable
