Huawei NetEngine40E

HUAWEI NetEngine40E Universal ServiceRouter
Hardware Description
B List of Boards
Issue 01 (2012-09-30)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
662
Board Name
Power
consumpti
on(Typical
value)
Heat
Dissipatio
n
Weight
16-Port 10GBase LAN-SFP+ Line
Processing Unit S(LPUS-100)
346 W
1122.57
BTU/hour
9.1 kg
( 20.07 lb )
1-Port 100GBase-CFP Line Processing
Unit S (LPUS-100)
339 W
1100
BTU/hour
9.2 kg
( 20.29 lb )
2-Port 10GBase LAN/WAN-XFP+24-Port
100/1000Base-X-SFP Line Processing Unit
S(LPUS-41)
190 W
616.44
BTU/hour
7.2 kg
( 15.88 lb )
24-Port 100/1000Base-X-SFP Integrated
Line Processing Unit L(LPUI-21-L)
155 W
502.89
BTU/hour
5.58 kg
( 12.30 lb )
1-Port 10GBase LAN/WAN-SFP+ +
16-Port 100/1000Base-X-SFP Integrated
Line Processing Unit L(LPUI-21-L)
150 W
486.67
BTU/hour
5.57 kg
( 12.28 lb)
Flexible Card Line Processing
Unit(LPUF-50,four slots)
184 W
596.97
BTU/hour
8.2 kg
( 18.08 lb )
2-Port 10GBase WAN/LAN-SFP+ Flexible
Card A
18.5 W
60.02
BTU/hour
0.5 kg ( 1.10
lb )
8-Port OC-3c/STM-1c ATM-SFP Flexible
Card
29 W
94.09
BTU/hour
0.6 kg ( 1.32
lb )
4-Port Channelized OC-3c/STM-1c
POS-SFP Flexible Card
34 W
110.31
BTU/hour
0.5 kg ( 1.10
lb )
8-Port Channelized OC-3c/STM-1c
POS-SFP Flexible Card
34 W
110.31
BTU/hour
0.5 kg ( 1.10
lb )
Flexible Card Line Processing
Unit(LPUF-51/LPUF-51-B,two sub-slots)
180 W
584
BTU/hour
6.55 kg
( 14.44 lb )
24-Port 100/1000Base-SFP Flexible Card
A(P51-A)
37 W
120.04
BTU/hour
1 kg ( 2.21
lb )
5-Port 10GBase LAN/WAN-SFP+Flexible
Card A (P51-A, two sub-slots)
29 W
94.09
BTU/hour
0.9 kg ( 1.98
lb )
2-Port 10GBase LAN/WAN-SFP+ Flexible
Card A(P51-A)
25 W
81.11
BTU/hour
0.88 kg
( 1.94 lb )
5-Port 10GBase LAN/WAN-SFP+
Integrated Line Processing Unit (LPUI-51)
209 W
678.08
BTU/hour
7.45 kg
( 16.43 lb )
4-Port 10GBase LAN/WAN-SFP+
Integrated Line Processing Unit (LPUI-51)
200 W
648.88
BTU/hour
7.45 kg
( 16.43 lb )
48-Port 100/1000Base-X-SFP Integrated
Line Processing Unit (LPUI-51)
253 W
820.84
BTU/hour
8.4 kg
( 18.52 lb )
2-Port 10GBase LAN/WAN-SFP+ +
242 W
785.15
8.28 kg
