Item Description
Shallow Dis. Test This item allows you to partially discharge
batteries. A shallow discharge test is conducted to
test the battery loop reliability and short-time
discharge capacity when the batteries have not
been discharged for a long time.
Capacity Test This item allows you to fully discharge batteries. A
deep discharge test is conducted to obtain the
battery discharge performance data.
USB Operations
You can export Fault Data, and perform Export
Cong., Upgrade Software, BSP
Upgrade, and Import Cong. on USB Operations.
Figure 4-45 USB Operations
Starting or Shutting Down the Inverter
Item
Description
Inv. ON Allows you to start the inverter manually.
Inv. OFF Allows you to shut down the inverter manually.
ECM Switchover
● Only professional personnel are allowed to use this function.
● Clear faults before performing ECM switchover.
● After an ECM is inserted, switchover is supported only after the ECM is
congured and starts working properly (about 30 seconds).
