Figure 3-87 Neutral wire
Single mains
For single mains, the copper bar between the mains and bypass input terminals do not
need to be removed, and bypass input cables do not need to be connected.
Step 5 Route signal cables. Bind cables to the cabinet.
Figure 3-88 Connecting signal cables
The number and colors of signal cables in Figure 3-88 are for reference only.
----End
