Huawei UPS5000-E Series User Manual

UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
4 User Interface
Issue 11 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
143
Item
Description
Hist. Max. Load Ratio (%)
Historical maximum load ratio of each phase on the UPS.
Hist. Max. Active Power (kW)
Historical maximum active power of each phase on the
UPS.
Hist. Max. Apparent Power
(kVA)
Historical maximum apparent power of each phase on the
UPS.
Table 4-5 Mains input
Item
Description
Phase voltage (V)
Mains input phase voltage
Line voltage (V)
Mains input line voltage
Phase current (A)
Mains input phase current
Frequency (Hz)
Mains input frequency
Power factor
Proportion of the mains input active power to the mains
input apparent power.
Table 4-6 Bypass input
Item
Description
Phase voltage (V)
Bypass input phase voltage
Line voltage (V)
Bypass input line voltage
Phase current (A)
Bypass input phase current
Frequency (Hz)
Bypass input frequency
Power factor
Proportion of the bypass input active power to the bypass
input apparent power.
Table 4-7 Battery status
Item
Description
Battery Status
The value can be Not connected, Equalized charging,
Float charging, Hibernating, discharging, or Not chg.
or dis.
Voltage (V)
Voltage of the battery string.
Current (A)
Current of the battery string (the current is + when
batteries are being charged and – when discharged).
