Figure 4-65 Buttons after one event is expanded
Table 4-25 Buttons after one event is expanded
No.
Name
Description
1
Button for modifying
A dialog box for modifying a job is
displayed after you click this button. You
can modify the job.
2
Button for deleting one job
You can delete the job by clicking this
button.
3
Button for test
If you click this button, the job will be
performed and a message showing test
succeeds or fails will be displayed on the
page.
Adding one job for one event: Select one event (for example, Inverter on), click the button
for adding one job, and the page for adding a job for the event is displayed.
When adding a job, the job types to be selected are: RCCMD Shutdown, RCCMD Message,
RCCMD Execute, and RCCMD TRAP. RCCMD Shutdown is selected by default. For
different job types, you need to enter different contents.

RCCMD Shutdown: You need to specify the RCCMD client IP address and port. When
the RCCMD client receives the job, it will shut down the computer.
