UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
5 Operations
Copyright © Huawei Technologies Co., Ltd.
233
Figure 5-17 Closing the maintenance bypass switch (UPS5000-E-200K-FM)
Figure 5-18 Closing the maintenance bypass switch (UPS5000-E-200K-FM, isolation protection)
