Huawei UPS5000-E Series User Manual

UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
3 Installation
Issue 11 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
55
Table 3-4 Power cable terminal requirements for the UPS5000-E-200K-FM
Port
Description
Connection
Method
Bolt
Specifications
Bolt Hole
Diameter
Bolt
Length
Torque
Mains input
Crimped OT
terminals
M10
10.5 mm
40 mm
26 N·m
Bypass input
Crimped OT
terminals
M10
10.5 mm
40 mm
26 N·m
Battery input
Crimped OT
terminals
M12
13.5 mm
60 mm
46 N·m
Output
Crimped OT
terminals
M10
10.5 mm
40 mm
26 N·m
PE
Crimped OT
terminals
M10
10.5 mm
30 mm
26 N·m
Table 3-5 lists the requirements for power cable terminals of the UPS5000-E-300K-SM/SMT.
Table 3-5 Power cable terminal requirements for the 300 kVA cabinet
Port
Description
Recommended
Connection
Method
Bolt
Specifications
Bolt Hole
Diameter
Bolt
Length
Torque
Mains input
Crimped OT
terminals
M12
13.5 mm
45 mm
46 N·m
Bypass input
Crimped OT
terminals
M12
13.5 mm
45 mm
46 N·m
Battery input
Crimped OT
terminals
M12
13.5 mm
45 mm
46 N·m
Output
Crimped OT
terminals
M12
13.5 mm
45 mm
46 N·m
PE
Crimped OT
terminals
M12
13.5 mm
30 mm
46 N·m
Table 3-6 Recommended upstream input and downstream output circuit breakers
Model
UPS
Capacity
Component
Specifications
a
UPS5000-E-200K-
SM/FM
50 kVA
Mains input circuit breaker
160 A/3P
Bypass input circuit breaker
100 A/3P
