Huawei UPS5000-E Series - Page 72

UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
3 Installation
Issue 11 (2019-12-20)
Copyright © Huawei Technologies Co., Ltd.
62
Figure 3-10 Removing the rear panel
Step 6 Remove the four plugs from the bottom of the cabinet (two at the front and two at the rear).
Figure 3-11 Removing plugs
