UPS5000-E-(50 kVA-300 kVA)
User Manual (50 kVA Power Modules)
Copyright © Huawei Technologies Co., Ltd.
Step 7 Insert four M12x115 expansion bolts into the expansion bolt holes in the floor, and tighten the
expansion bolts in the direction.
Figure 3-12 Tightening expansion bolts
----End
Unsecured Installation
Step 1 Adjust the four anchor bolts at the bottom of the UPS cabinet until all the four castors at the
bottom hang in the air and the anchor bolts bear all of the cabinet weight, as shown in Figure
3-13.
Figure 3-13 Castors adjustment
Step 2 Check the cabinet levelness using a level. If the cabinet is not level, wrench the anchor bolts.
----End
