IAI ROBO Cylinder RCP6 User Manual

117
6. External Dimensions
6.5 Standard Specification RCP6-RA7C
ST : Stroke
M.E. : Mechanical End
S.E. : Stroke End
Stroke
L
A
Mass [kg]
W/o
Brake
With
Brake
W/o
Brake
With
Brake
50
354.5
404.5
214.5
4.5
4.9
100
404.5
454.5
264.5
5.1
5.5
150
454.5
504.5
314.5
5.6
6.0
200
504.5
554.5
364.5
6.2
6.6
250
554.5
604.5
414.5
6.7
7.2
300
604.5
654.5
464.5
7.3
7.7
(Note) L dimensions described in the table are those with no cable exit direction (option). For cable exit
direction types (option), the dimensions are longer in 25mm.
Enclosed
hexagonal nut
Greasing Port
(ø5 hole)
Home
4-M8 Depth 16
The angle of the width
across
flat is undefined.
Greasing Port (ø5 hole)
(The same applies to
the other side)
CJR
Right
CJB
Bottom
2-M3 Depth 6
(For ground
connection)
M14X1.5
Cable Exit Direction (Optional)
140 (W/o Standard Brake)
190 (With Standard Brake)
Detailed View P
Scale 1 : 1
2-M3 Depth 6
(For ground
connection)
Disabled
when CJL
is selected.
Disabled
when CJR
is selected.
Maintain it more
than 100
M14X1.5
CJT
Top
CJL
Left
