1. Specifications Check
1. Specifications Check
1.1 Checking the Product
The standard configuration of this product is comprised of the following parts.
See the component list for the details of the enclosed components. If you find any fault or missing
parts, contact your local IAI distributor.
1.1.1 Parts
No. Name Model number
Quantity Remarks
1 Actuator
Refer to “How to
Read the Model
Nameplate” and
“How to Read the
Model Number.”
1
Accessories
2
Motor • Encoder Cables
(Note1)
1
3
Nut
1
Refer to list below
4
Square T-nut
1 set
Refer to list below
5
First Step Guide
1
6
Instruction Manual (DVD)
1
7
Safety Guide
1
Note 1 The motor • encoder cables supplied vary depending on the controller used. [Refer to 1.4,
“Motor • Encoder Cables.”]
[List of Included Nut Type]
Nut (M10×1.25)
Nut (M14×1.5)
Nut (M20×1.5)
RA4C, RA4R
RA6C, RA6R
1
RA7C, RA7R
1
RA8C, RA8R
1
[Refer to 6. “External Dimensions” for the dimensions of nuts.]
[List of Included Square T-nut Type]
Square T-nut
Quantity
RA4C, RA4R
M4 □7×3.2
4
RA6C, RA6R
M6 □10×5
4
RA7C, RA7R
M6 □10×5
8
RA8C, RA8R
M8 □13×6.5
8
