2. Installation
[2] Handling in the Assembled Condition
This is the case when the product is delivered from our factory under a condition that it is
assembled with other actuators. The combined axes are delivered in a package that the frame is
nailed on the lumber base. Fix the rod so that would not accidentally move during transportation.
The actuators are also fixed so the tip of it would not shake due to the external vibration.
(1) Handling the Packed Unit
• Do not hit or drop the package. No special treatment is conducted on this package to endure a
drop or impact on it.
• Do not attempt to carry a heavy package with only one worker. Also, have an appropriate
method for transportation.
• When hanging up with ropes, support on the reinforcement frame on the bottom of the lumber
base. When bringing up the package with a forklift, also support on the bottom of the lumber
base.
• Handle with care when putting the package down to avoid impact or bounce.
• Do not step on the package.
• Do not put any load that may cause a deformation or breakage of the package.
(2) How to Handle after Unpackaged
• Secure the rods to prevent sudden movement during transport.
• If the tip of an actuator is overhanging, have an appropriate way to fix it to avoid shake due to the
external vibration. In the transportation without the tip being fixed, do not apply any impact with
0.3G or more.
• When hanging up with ropes, have appropriate cushioning to avoid any deformation of the
actuator body. Also keep it in stable horizontal orientation. Make a fixture utilizing the attachment
holes and the tapped holes on the actuator body if necessary.
• Do not attempt to apply load on the actuators or the connector box. Also pay attention not to
pinch cables and bend or deform them forcefully.
[3] Handling in Condition of being assembled in Machinery Equipment (System)
These are some caution notes for when transporting the actuator being assembled in the
machinery equipment (system):
• Secure the rods to prevent sudden movement during transport.
• If the tip of an actuator is overhanging, have an appropriate way to fix it to avoid shake due to the
external vibration. In the transportation without the tip being fixed, do not apply any impact with
0.3G or more.
• When hanging up the machinery equipment (system) with ropes, do not attempt to apply load on
the actuators or the connector box. Also pay attention not to pinch cables and bend or deform
them forcefully.
