3. Operation
186
Procedure 2)
In case the condition has not improved in Procedure 1, try to change the pressing gain
with force censor use (Parameter No. 94).When changing the setting, increase or
decrease gradually
(Note 2)
referring to the following table.
Note 2 Try those values below (for each model) for the setting value in Parameter No. 94,
174, 175 and 176.
◎RA13R、RA10R * At delivery from factory
Rigidity of pressing target
Hard ← Rigidity → Soft
1050 2100 4200 8400 16800 33600
1200 2400 4800 9600 19200 38400
1350 2700 5400 10800 21600 43200
1500
(*)
3000 6000 12000 24000 48000
1650 3300 6600 13200 26400 52800
1800 3600 7200 14400 28800 57600
Responsiveness of Control
System
High ← Response → Low
1950 3900 7800 15600 31200 62400
◎RA8R * At delivery from factory
Rigidity of pressing target
Hard ← Rigidity → Soft
2100 4200 8400 16800 33600 67200
2400 4800 9600 19200 38400 76800
2700 5400 10800 21600 43200 86400
3000
(*)
6000 12000 24000 48000 96000
3300 6600 13200 26400 52800 105600
3600 7200 14400 28800 57600 115200
Responsiveness of Control
System
High ← Response → Low
3900 7800 15600 31200 62400 124800
◎RA7R * At delivery from factory
Rigidity of pressing target
Hard ← Rigidity → Soft
3500 7000 14000 28000 56000 112000
4000 8000 16000 32000 64000 128000
4500 9000 18000 36000 72000 144000
5000
(*)
10000 20000 40000 80000 160000
5500 11000 22000 44000 88000 176000
6000 12000 24000 48000 96000 192000
Responsiveness of Control
System
High ← Response → Low
6500 13000 26000 52000 104000 208000
3.2.4
