8. Parameter
302
[61] Electromagnetic brake power monitor (Parameter No.75)
No. Name Symbol Unit Input Range
Default factory
setting
75
Electromagnetic brake power
monitor
FSTP –
0: Disabled
1: Enabled
In accordance with
actuator
A power monitor function is provided to prevent actuator malfunction or breakdown of parts
caused by an abnormal voltage of the 24V DC brake power supply when an actuator with brake
is used.
Normally this parameter need not be changed because it has been set properly prior to the
shipment in accordance with the actuator, i.e. whether or not the actuator is equipped with
brake.
Set Value Description
0 Disabled (no brake)
1 Enabled (with brake)
[62] Belt breaking sensor input polarity (Parameter No.76)
No. Name Symbol Unit Input Range
Default factory
setting
76
Belt breaking sensor input
polarity
AIOF – 0 to 2
In accordance with
actuator
Set the sensor input polarity for Alarm Code 0D7 “Belt Break Detection” for Ultra-High Thrust
Type RCS2-RA13R.
Parameter No. Set Value
not used 0
Input is a contact 1
76
Input is b contact 2
[63] Ball Screw Lead Length (Parameter No.77)
No. Name Symbol Unit Input Range
Default factory
setting
77 Ball Screw Lead Length LEAD mm 0.01 to 999.99
In accordance with
actuator
This parameter set the ball screw lead length.
The factory setting is the value in accordance with the actuator characteristics.
Caution: If this parameter is set to “Disabled”, no brake control is provided.
Caution: Changing the setting of this parameter disables the alarm to be detected.
Caution: If the setting is changed, not only the normal operation with indicated speed,
acceleration or amount to move is disabled, but also it may cause a
generation of alarm, or malfunction of the unit.
