IAI SCON-CB-F User Manual

10. Appendix
420
Motor
Output
Lead
Maximum
Speed
Maximum
Acceleration/
Deceleration Speed
Minimum
Pressing
Force
Maximum
Pressing
Force
Rated
Pressing
Speed
Actuator
Series
Type
[W]
No. of
Encoder
Pluses
[mm]
Oriented
Direction
[mm/s] [G] [N] [N] [mm/s]
600
(at to 650st)
− − −
585
(at to 700st)
− − −
520
(at to 750st)
− − −
470
(at to 800st)
− − −
425
(at to 850st)
− − −
385
(at to 900st)
− − −
Horizontal
350
(at to 950st)
1
− − −
320
(at to 1000st)
− − −
295
(at to 1050st)
− − −
275
(at to 1100st)
− − −
255
(at to 1150st)
− − −
235
(at to 1200st)
− − −
220
(at to 1250st)
− − −
10
Vertical
205
(at to 1300st)
1
− − −
1200
(at to 650st)
− − −
1165
(at to 700st)
− − −
1045
(at to 750st)
− − −
940
(at to 800st)
− − −
850
(at to 850st)
− − −
770
(at to 900st)
− − −
Horizontal
705
(at to 950st)
1
− − −
645
(at to 1000st)
− − −
595
(at to 1050st)
− − −
545
(at to 1100st)
− − −
505
(at to 1150st)
− − −
470
(at to 1200st)
− − −
440
(at to 1250st)
− − −
ISDB
ISPDB
(Slider Type)
L
(Note)
200
400
16384
20
Vertical
410
(at to 1300st)
1
− − −
(Note) The model stated in the hatched area is applicable for the offboard tuning function (except for the setting for
the high acceleration/deceleration type if any).
For the off board tuning function, refer to the instruction manual for RC PC Software.
